Intel Alder Lake-N N100
SODIMM Single channel DDR5-4800
M.2 2280 PCIe Gen 3 x 4 SSD
€ 399,00 € 279,00
Mini Air12 Mini PC
Power beyond lightness.
Mini Air12 Mini PC
Power beyond lightness.
Intel Alder Lake-N N100
SODIMM Single channel DDR5-4800
M.2 2280 PCIe Gen 3 x 4 SSD
3 Displays
8K
MiniDP 1.4 * 1
USB3.2 Gen2 Type C * 1
WiFi 6 Bluetooth 5.2
Intel
Alder Lake-N N100
SODIMM
Single channel DDR5-4800
M.2 2280 PCIe
Gen 3 x 4 SSD
3 Displays
MiniDP 1.4 * 1
USB3.2 Gen2 Type C * 1
WiFi 6
Bluetooth 5.2
12th generation Intel
Alder Lake N100.
6 W
TDP
3.4 GHz
Maximum turbo frequency
4/4
Core/Thread
6 MB
L3 cache
Celeron N5095
+36%
12th generation Intel
Alder Lake N100
6 W
TDP
3.4 GHz
Maximum turbo frequency
4/4
Core/Thread
6 MB
L3 cache
Celeron N5095
+36%
Higher frequency DDR5,
greater capacity and greater energy efficiency.
Compared to DDR4, DDR5 increases the transfer speed to 4800 MHZ.
DDR5
4800MHz
DDR4
3200MHz
DDR5
4800MHz
DDR4
3200MHz
Up to 2TB M2 PCIe Gen3 NVMe SSD.
PCIe 3.0 SSD is 7 times faster at data access than SATA3 SSD, greatly reducing loading times and improving work efficiency.
PCIe 3.0 NVMe SSD
3500MB/s
SATA3 SSD
550MB/s
550MB/s
PCIe 3.0 NVMe SSD
3500MB/s
SATA3 SSD
550MB/s
Supports 3 displays, up to 8K.
Connect 3 monitors simultaneously and enhance your productivity and entertainment experience like never before.
USB 3.2 Gen 2
Type-C(8K @30Hz)
MiniDP 1.4
(8K @30Hz)
HDMI 2.0
(4K @60Hz)
Multifunctional connections to meet all your needs.
Fast and stable wireless connection
The Wi-Fi 6 and Bluetooth 5.2 of the MiniAir 12 ensure smooth speeds and stable transmissions even when multiple devices are connected. They reduce delays and allow you to complete tasks efficiently, anytime, anywhere.
WI-FI 6
Bluetooth 5.2
High efficiency and low noise cooling system.
The specially designed built-in fan runs smoothly and silently, ensuring excellent cooling effect and stable operation of the machine for a long time. The fan has a power of only 45.7 db at maximum pressure, to keep the working environment silent.
Extremely compact.
The GEEKOM Mini Air12 measures 4.6 x 4.4 1.4 inches and weighs just 498 g. Easy to store and carry in your bag.
Say goodbye to messy desk.
With the VESA mount, you can mount the Mini PC on the back of the monitor.
Extremely compact.
The GEEKOM Mini Air12 measures 4.6 x 4.4 1.4 inches and weighs just 498 g. Easy to store and carry in your bag.
Say goodbye to messy desk.
With the VESA mount, you can mount the Mini PC on the back of the monitor.
IIGEEKOM Mini PC Air12 can be used for
Dimension | 117 x 112 x 34.2mm | |
CPU | Intel Alder Lake N100 (4 cores, 4 threads, 6 MB cache, up to 3.4 GHz) | |
TDP 6W | ||
Graphic card | Intel UHD 12a graphics | |
Memory | Single-channel DDR5 SODIMM, 4800MT/s, up to 16GB | |
Audio | HDA CODEC | |
Storage |
1 x SSD (2280 M.2 SATA and PCIE Gen 3*4), 512G, up to 1TB |
|
I/O port | 1 x USB 3.2 Gen 2 x 1 port (front panel) and 2 x USB 3.2 Gen 2 ports (rear panel) | |
1 x TYPE-C with DP 1.4 Alt mode (rear panel) and 1 x TYPE-C data only (front panel) | ||
1 x SD Card Reader | ||
1 x 3.5mm headphone jack (front panel, supports Apple HeadPhone) | ||
1 x RJ45 (back panel) | ||
1 x HDMI 2.0 (rear panel) | ||
1 x Mini DP 1.4 (back panel) | ||
1 x DC Input (rear panel) | ||
1 x Power Button | ||
1 x Kensington Lock | ||
What's inside | 1 x M.2 key-M slot (PCIe/SATA) | |
1 x FAN | ||
1 x RTC | ||
1 x USB2 | ||
LEDs | 1 x Power LED (Power: Blue, S3: Flashing Orange) | |
1 x SATA SSD: Red PCIE SSD: Green | ||
Ethernet | Intel® 10/100/1000 Mbps Ethernet | |
LEDs | 10-100M: Orange flashing, Green, 1000M: Orange flashing, Green No light | |
Wifi | WiFi6 on board, BT5.2 AW-XM548NF | |
Kensington lock | Yes | |
Drums | RTC button battery | |
Adapter | Automatic voltage regulation between 100 and 240V AC, 50/60Hz, 45Watt (19V/2.36A), 3Pin, 1.8 meters long and 65W (19V/3.42A) | |
PCBA size | 109.1 x 107.63mm | |
Certification | CE, RoHS, FCC, CEC, CB, PSE, TELEC | |
Operating system | Windows 11 21H2, PRO | |
Accessory | VESA mounting |
